Iron remover is a kind of equipment that can generate strong magnetic field attraction. It can remove the ferromagnetic impurities mixed in the material to ensure the safe operation of the crusher, grinder and other mechanical equipment in the conveying system, and can effectively prevent the cause. The accident of large and long iron pieces cracking the conveyor belt can also significantly improve the raw material grade. According to the method of unloading iron, it can be divided into various working modes such as manual unloading of iron, automatic unloading of iron and program control of unloading iron. Due to different use occasions and magnetic circuit structure, various series of products are formed.

        Principle: When the bulk material conveyed by the belt conveyor passes through a magnetic separator (ie, a rotating DC magnet) mounted on the tail bracket, the ferromagnetic debris in the material is sucked, and the ferromagnetic debris is removed by the discarding iron tape. When the electric drum is removed, the effect of braking and iron removal is achieved.

        Iron separators are widely used in metallurgy, mining, coal preparation plants, power plants, ceramics, glass, cement, building materials, chemicals, food and feed processing industries. In the emerging waste treatment industry, iron in iron recycling waste is also required. Iron removers have been used in major steel companies, as well as in metal mines, power plants, light industry, refractory materials, etc., and have played a huge role.

        The iron remover is suitable for removing iron from various industries, and can continuously absorb and reject iron.

Classification of iron separators:

        Self-cooling electromagnetic self-unloading iron remover, self-cooling electromagnetic iron remover, permanent magnetic cylinder magnetic separator, suspended oil-cooled electromagnetic iron remover, suspended cold-air electromagnetic iron remover, manual permanent magnet iron remover, lifting electromagnet, Skid-mounted permanent magnet self-unloading iron remover and dry self-unloading electromagnetic iron remover are divided into automatic iron removal and manual iron removal according to the method. According to the model, it can be divided into RCDB, RCDD and RCDE.

Main features of electromagnetic separator

1. The fully sealed natural cooling structure can effectively prevent the immersion of moisture, dust and harmful gases on the iron separator coil. It has strong adaptability to climate and environment, reasonable structure, convenient operation and maintenance, and safe and reliable use.

2, using the best magnetic circuit design, the magnetic permeability is large, and the geometry of the magnetic field is approximately rectangular hemisphere, so it has stronger iron removal ability than other similar products.

3. The iron separator coil is treated by special process to improve the electrical and mechanical properties of the coil. The coil has good integrity, fast heat dissipation, low temperature rise and long service life.

4, the product supporting performance is good, a variety of rectifier equipment features are available, can adapt to the use of various occasions.

Main features of permanent magnet separator

1. A strong magnetic core composed of high-strength permanent magnets can absorb ferromagnetic debris buried in the material. It also saves a lot of power.

2. The magnetic field distribution is reasonable, the magnetic permeability is large, and the constant attenuation of the magnetic field is small. At the same time, the magnetic pole has a large adsorption area, which ensures sufficient time to pick up ferromagnetic debris from the moving material.

3. The structure of the whole machine is simplified compared with the electromagnetic iron remover. There is no need for a rectifying excitation system, no cooling system, and no metal control tester is required. Long-term trouble-free operation is guaranteed.
